Запчасти Komatsu PC300LC-6LC FIG. P-A МОТОР ХОДА - СТАНДАРТН. - КРЫШКАASSEMBLY - ДЛЯ PCLC- НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$1

706-88-00020

COVER ASSEMBLY, END

1

NSS

O-RING

2

NSS

O-RING

3

NSS

BOLT

4

NSS

SHAFT, DRIVE

5

NSS

BEARING

6

NSS

RETAINER

7

NSS

O-RING

8

NSS

KIT, SPACER

|$10

NSS

SPACER, 1.6 MM

|$11

NSS

SPACER, 1.7 MM

|$12

NSS

SPACER, 1.8 MM

9

NSS

RING, SNAP

10

708-8K-12141

SEAL, OIL

11

706-88-40710

HOUSING

12

07000-02135

O-RING

13

04071-00140

RING, SNAP

14

NSS

BLOCK, CYLINDER

15

NSS

SHAFT, CENTER

16

NSS

RING, CENTER

17

NSS

SPRING

|$22

706-88-05020

KIT, RETAINER

18

NSS

RETAINER

19

NSS

SCREW

20

NSS

PISTON SUB ASSEMBLY

|$26

NSS

PISTON SUB ASSEMBLY

|$27

NSS

PISTON SUB ASSEMBLY

21

NSS

PLATE

22

NSS

DISC

23

NSS

PISTON, BRAKE

24

NSS

O-RING

25

NSS

RING, BACK-UP

26

NSS

O-RING

27

NSS

RING, BACK-UP

28

NSS

SPRING
