Запчасти Komatsu PC300LC-6LC FIG. P-A МОТОР ХОДА - УСИЛ. - КОРПУС ASSEMBLY - ДЛЯ PCHD- заводской номер A8 И UP НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

706-88-00150

MOTOR ASSEMBLY, TRAVEL

1

NSS

CASE, MOTOR

|$2

706-88-00020

COVER ASSEMBLY, END

2

NSS

COVER, END

3

NSS

PLATE, VALVE

4

NSS

SPOOL

5

NSS

PLUG

6

NSS

PIN, DOWEL

7

707-77-72280

PLUG

8

07002-12034

O-RING

9

20B-27-11210

BLEEDER

10

NSS

PISTON

11

NSS

PIN

12

NSS

SCREW

13

706-75-74540

VALVE

14

706-75-74550

SPRING

15

706-75-74850

PLUG

16

07002-13334

O-RING

17

706-78-71170

PISTON

18

708-8H-36121

SPRING

19

706-78-71140

PLUG

20

07002-13634

O-RING

21

706-88-50110

SLEEVE

22

07002-15234

O-RING

23

07000-13035

O-RING

24

07001-03035

RING, BACK-UP

25

07000-13038

O-RING

26

07001-03038

RING, BACK-UP

27

706-8E-14170

SPRING

28

706-88-50140

SPOOL

29

706-88-50160

PLUG

30

07002-13034

O-RING

31

706-88-50170

PLUG

32

07002-13034

O-RING

33

04260-00793

BALL

34

706-8E-14110

PLUG

35

07002-11023

O-RING

36

708-8E-16180

VALVE

37

706-78-71150

VALVE

38

708-8E-16160

PLUG

39

07002-11023

O-RING

40

706-78-71130

PLUG

41

07002-11423

O-RING

42

07000-11007

O-RING

43

07001-01007

RING, BACK-UP
