Запчасти Komatsu PC300LC-6LC FIG. P-A МОТОР ХОДА - УСИЛ. - КРЫШКАASSEMBLY - ДЛЯ PCHD- заводской номер A8 И BEНИЗ. НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$3

706-88-00020

COVER ASSEMBLY, END

1

NSS

COVER, END

2

NSS

PLUG

3

706-88-40310

BOLT

4

708-8K-15190

PIN, DOWEL

5

706-88-50030

PISTON

6

706-88-50010

PIN

7

706-87-51120

SCREW

8

706-88-50110

SLEEVE

9

706-88-50140

SPOOL

10

07002-15234

O-RING

11

07000-13035

O-RING

12

07001-03035

RING, BACK-UP

13

07000-13038

O-RING

14

07001-03038

RING, BACK-UP

15

706-88-50160

PLUG

16

07002-13034

O-RING

17

706-8E-14170

SPRING

18

706-88-50170

PLUG

19

NSS

SPOOL

20

706-8E-14110

PLUG

21

07002-11023

O-RING

22

04260-00793

BALL

23

706-78-71170

PISTON

24

708-8H-36121

SPRING

25

706-78-71140

PLUG

26

07002-13634

O-RING

27

706-75-74540

VALVE

28

706-75-74550

SPRING

29

706-75-74850

PLUG

30

07002-13334

O-RING

31

708-8E-16180

VALVE

32

706-78-71150

VALVE

33

708-8E-16160

PLUG

34

07002-11023

O-RING

35

706-77-72280

PLUG

36

07002-12034

O-RING

37

706-78-71130

PLUG

38

07002-11423

O-RING

39

07000-11007

O-RING

40

07001-01007

RING, BACK-UP

41

20B-27-11210

BLEEDER
