Запчасти Komatsu PC300LC-6LC FIG. P-A МОТОР ХОДА - УСИЛ. - КОРПУС ASSEMBLY - ДЛЯ PCHD- заводской номер A8 И BEНИЗ. НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

706-88-00150

MOTOR ASSEMBLY, TRAVEL

1

706-88-40110

CASE, MOTOR

2

706-88-40370

O-RING

3

07000-12012

O-RING

4

706-88-40660

SHAFT, DRIVE

5

706-88-40880

BEARING

6

706-88-40890

BEARING

7

706-88-40810

RETAINER

|$8

706-88-05010

KIT, SPACER

8

NSS

SPACER, 1.6 MM

9

NSS

SPACER, 1.7 MM

10

NSS

SPACER, 1.8 MM

11

04064-07525

RING, SNAP

12

706-88-40160

PISTON SUB ASSEMBLY

13

706-88-40260

RETAINER

14

708-23-12350

SCREW

15

706-88-40080

SHAFT, CENTER

16

706-88-40130

RING, CENTER

17

706-88-40060

SPRING

18

706-88-40090

BLOCK, CYLINDER

19

706-88-00010

PLATE, VALVE

20

706-88-40710

HOUSING

21

708-8K-12141

SEAL

22

07000-02135

O-RING

23

04071-00140

RING, SNAP

24

706-88-90140

PLATE

25

706-88-90150

DISC

26

706-88-90180

PISTON, BRAKE

27

07000-15240

O-RING

28

706-88-90130

RING, BACK-UP

29

07000-15270

O-RING

30

07001-05270

RING, BACK-UP

31

706-88-90410

SPRING
