Запчасти Komatsu PC300LC-6LC FIG. P-A МОТОР ХОДА - СТАНДАРТН. - КРЫШКАASSEMBLY - ДЛЯ PCLC- НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$1

708-8H-04651

COVER SUB ASSEMBLY

1

708-8H31530

COVER

2

NSS

SPOOL

3

NSS

SPOOL

4

NSS

PLUG

5

706-8E-14110

PLUG

6

07002-11023

O-RING

7

04260-00793

BALL

8

708-8H-34170

SPRING

9

708-8H-34210

SEAT

10

708-8H-34180

RING

11

706-78-71160

PISTON

12

708-8H-36121

SPRING

13

708-8H-16141

PLUG

14

07002-13634

O-RING

15

706-73-72420

VALVE

16

706-73-72440

SPRING

17

708-8H-36150

PLUG

18

07000-12018

O-RING

19

07001-02018

RING, BACK-UP

20

708-8H-11530

PLUG

21

07002-11423

O-RING

22

20B-27-11210

BLEEDER

23

01252-62055

BOLT

24

01252-62095

BOLT

25

07000-12012

O-RING

26

708-8E-16180

VALVE

27

708-8E-16160

PLUG

28

07002-11023

O-RING

29

708-18-13230

PIN

30

706-75-42820

PIN

31

708-8E-16180

VALVE

32

708-8E-16160

PLUG

33

07002-11023

O-RING
