Запчасти Komatsu PC300LC-6LC FIG. P-A МОТОР ХОДА - СТАНДАРТН. - КОРПУС ASSEMBLY - ДЛЯ PCLC- НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

708-8H-00250

MOTOR ASSEMBLY, TRAVEL

|$1

708-8H-04640

CASE, MOTOR

1

708-8H-31130

CASE

2

NSS

PLUG

3

708-8H-31210

O-RING

4

04020-01228

PIN

5

708-8H-32111

SHAFT

6

708-8H-32150

BEARING

7

708-8H-32140

BEARING

|$9

708-8H-05030

KIT, SPACER

8

NSS

SPACER, 1.6 mm

9

NSS

SPACER, 1.7 mm

10

NSS

SPACER, 1.8 mm

11

NSS

SPACER, 1.9 mm

12

NSS

SPACER, 2.0 mm

13

NSS

SPACER, 2.1 mm

14

NSS

SPACER, 2.2 mm

15

708-1F-12281

SEAL

16

708-8H-32160

SPACER

17

04065-07825

RING

18

708-8H-33112

BLOCK

19

708-8H-33220

PLATE

20

708-8H-33360

PIN

21

708-8H-33141

SPACER

22

708-7H-13150

SPRING

23

04065-06020

RING

24

708-8H-33340

RETAINER

25

708-8H-33512

RETAINER

26

708-8H-33610

PISTON

27

708-8H-33431

CAM

28

04260-02857

BALL

29

708-8H-34143

PISTON

30

708-8H-34151

SPRING

31

708-8K-14210

PLUG

32

07002-13334

O-RING

33

708-8H-35141

PISTON, BRAKE

34

07000-15175

O-RING

35

07001-05175

RING, BACK-UP

36

07000-15195

O-RING

37

07001-05195

RING, BACK-UP

38

708-8H-35150

SPRING

39

708-8H-35130

PLATE

40

708-8H-35120

DISC
