Запчасти Komatsu PC300LC-6LC FIG. P-A КОНЕЧНАЯ ПЕРЕДАЧА - PCHD- заводской номер A8 И BEНИЗ. НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

208-27-00152

FINAL DRIVE ASSEMBLY

|$1

208-27-00140

SEAL ASSEMBLY, FLOATING

|$2

208-27-00130

RING ASSEMBLY, SEAL

1

NSS

RING

|$4

421-33-00030

O-RING ASSEMBLY

2

NSS

O-RING

3

208-27-61191

HUB

4

208-27-62110

BEARING

5

208-27-51212

COVER

6

01010-51240

BOLT

7

01643-31232

WASHER

8

207-27-52350

O-RING

9

207-27-61270

LOCK

10

207-27-61261

NUT

11

01010-81020

BOLT

12

208-27-61170

CARRIER

13

208-27-61140

GEAR

14

207-27-61230

BEARING

15

20Y-27-21250

WASHER

16

207-27-61250

PIN

17

20Y-27-21290

PIN

18

207-27-52270

SPACER

19

208-27-61130

GEAR

20

208-27-61150

GEAR

21

208-27-61160

CARRIER

22

208-27-61121

GEAR

23

207-27-61220

BEARING

24

20Y-27-21240

WASHER, THRUST

25

207-27-61240

PIN

26

20Y-27-21280

PIN

27

208-27-61111

SHAFT

28

20Y-27-11250

SPACER

29

208-27-61350

BUTTON

30

208-27-61180

COVER

31

207-27-52341

BOLT

32

01643-31845

WASHER

33

07049-01215

PLUG

34

07044-12412

PLUG

35

07002-02434

O-RING

36

208-27-61210

SPROCKET

37

207-27-51311

BOLT, MOUNT SPROCKET

38

01011-52000

BOLT

39

01643-32060

WASHER

40

208-30-61241

BOLT

41

01010-61640

BOLT

42

01643-31645

WASHER
