Запчасти Komatsu PC300LC-6LC FIG. K-A PPC ЛИНИЯ - НАВЕСН. ОБОРУД - АКТУАТОР С ДАТЧИКОМS КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-62-23410

HOSE, 1950 mm

2

20Y-62-23570

HOSE, 1900 mm

3

20Y-62-22810

BAND, YELLOW

4

20Y-62-22170

CLAMP

5

20Y-62-22180

CLAMP

6

01010-81016

BOLT

7

01643-31032

WASHER

8

08034-20536

STRAP, TIE

9

203-62-58470

CLIP

10

01010-81225

BOLT

11

01643-31032

WASHER

12

20Y-62-22881

HOSE, 980 mm

13

20Y-62-23370

HOSE, 1200 mm

14

20Y-62-25550

HOSE, 2150 mm

15

20Y-62-25560

HOSE, 2200 mm

16

20Y-62-22170

CLAMP

17

20Y-62-22860

BAND, BROWN

18

20Y-62-22790

BAND, RED

19

20Y-62-22840

BAND, BLACK

20

20Y-62-22820

BAND, BLUE

21

20Y-62-22180

CLAMP

22

01010-81016

BOLT

23

01643-31032

WASHER

24

08034-20536

STRAP, TIE

25

20Y-62-22220

BLOCK

26

01010-81010

BOLT

27

01643-31032

WASHER

28

08053-01512

CLIP

29

20Y-62-16630

NIPPLE

30

201-60-11390

O-RING

31

20Y-62-19560

O-RING

32

07002-11423

O-RING

33

206-06-61130

SWITCH

34

20Y-06-22430

HARNESS, WIRE
