Запчасти Komatsu PC300LC-6LC FIG. A-AB ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ

|$0

1307 231 H91

TURBOCHARGER ASSEMBLY (HX40W)

|$1

NSS

TURBOCHARGER

1

6736-81-8370

BEARING, TURBOCHARGER

2

6731-81-8160

NUT, LOCK(M7-1.00)

3

6736-81-8480

SCREW, DRIVE

4

6736-81-8430

SHIELD, TURBOCHARGER HEAT

5

1294 841 H1

SHAFT & WHEEL

6

6733-81-8360

RING, RETAINING

7

NSS

DATAPLATE

8

6733-81-8330

BAFFLE, OIL

9

NSS

END, ADJUSTING LINK

10

6733-81-8250

NUT, LOCK (1/4 - 28 UNF)

11

6733-81-8370

RING, RETAINING

12

6733-81-8810

NUT, REG HEX JAM

13

6733-81-8460

SEAL, O-RING

14

6733-81-8380

BOLT (M8-1.25x20)

15

6733-81-8270

PLATE, OIL SEAL

16

NSS

SLINGER, OIL

17

6732-82-8800

KIT, WASTEGATE ACTUATOR

18

6735-81-8610

BEARING, THRUST

19

6735-81-8620

COLLAR, THRUST

20

1307 199 H1

IMPELLER, COMPRESSOR

21

1304 922 H1

HOUSING, COMPRESSOR

|$23

6735-81-8510

HOUSING ASSEMBLY, TURBOCHARGER BRG

22

6733-81-8480

PIN, ROLL

23

NSS

HOUSING, TURBOCHARGER BEARING

24

1307 693 H1

CONNECTION, ADAPTER

25

6733-81-8650

WASHER, PLAIN

26

6733-81-6850

SPACER, MOUNTING

27

6735-81-6810

SPACER, MOUNTING

28

6742-01-5569

BOLT

29

NSS

BRACKET, ACTUATOR

30

6735-81-8370

BOLT

31

1304 929 H1

HOUSING, TURBINE

32

6735-81-8310

RING, RETAINING

33

1304 920 H1

PLATE, CLAMPING

34

1304 921 H1

GASKET, ADAPTER

35

6736-81-8440

SEAL, SPLIT RING

36

6736-81-8320

SEAL, SPLIT RING

37

6736-81-8380

BOLT (M8-1.25x12)

38

6736-81-8360

RING, RETAINING

39

NSS

SEAL, O-RING

40

6736-51-8140

CONNECTOR, FEMALE

41

6742-01-0790

GASKET, TURBOCHARGER
