Запчасти Komatsu PC300LC-6 ЦИЛИНДР СТРЕЛЫ(MIZUGURI СПЕЦ-Я.)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

707-01-14830

CYLINDER ASS'Y,L.H.

|1

707-01-14840

CYLINDER ASS'Y,R.H.

1

207-63-53541

CYLINDER

2

707-76-90390

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

07043-00108

PLUG

6

207-63-53520

ROD

7

707-76-10130

BUSHING

8

07145-00100

SEAL,DUST (KIT)

9

707-71-32880

COLLAR

10

707-35-91420

RING,BACK-UP (KIT)

11

07000-15130

O-RING (KIT)

12

707-71-61060

PLUNGER

13

707-27-14930

HEAD

14

707-56-10110

SEAL,DUST (KIT)

15

707-75-10040

RING,SNAP

16

707-52-90780

BUSHING

17

707-51-10030

PACKING,ROD (KIT)

18

707-51-10530

RING,BUFFER (KIT)

19

707-35-91420

RING,BACK-UP (KIT)

20

07000-15130

O-RING (KIT)

21

01010-81875

BOLT

22

707-41-11840

WASHER

23

707-36-14410

PISTON

24

01310-01216

SCREW

25

707-44-14180

RING,PISTON (KIT)

26

707-39-14820

RING,WEAR (KIT)

27

707-44-14910

RING

28

07001-05090

RING,BACK-UP (KIT)

29

07000-15090

O-RING (KIT)

30

207-63-53571

TUBE,L.H.

|30

207-63-53671

TUBE,R.H.

31

207-63-53181

TUBE,L.H.

|31

207-63-53281

TUBE,R.H.

32

01435-01055

BOLT

33

07000-13035

O-RING (KIT)

34

707-88-95731

BRACKET

35

707-88-95720

BAND

36

01010-81240

BOLT

37

01643-51232

WASHER

38

07283-23442

CLIP

39

01643-31032

WASHER

40

01599-01011

NUT

41

01010-81025

BOLT

42

01643-31032

WASHER

43

707-88-33040

CAP

44

07371-31049

FLANGE,SPLIT

45

07372-21035

BOLT

46

01643-51032

WASHER

|K

707-99-58140

SERVICE KIT
