Артикул
Название
Примечание
Количество
|1
723-48-18101
CONTROL VALVE
|1
723-48-18100
CONTROL VALVE
|1
723-48-16102
CONTROL VALVE
|1
723-48-16101
CONTROL VALVE
|1
723-48-16100
CONTROL VALVE
|$$6
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1664-01A0 TO Y1664-15A0.
|1
709-70-74302
VALVE ASS'Y,SUCTION AND SAFETY
1
SLEEVE
2
SLEEVE
3
POPPET
4
PISTON
5
PLUG
6
POPPET
7
SCREW
8
SPRING
9
SPRING
10
SPRING
11
SEAL
12
SEAL
13
709-25-11390
O-RING
14
O-RING
15
O-RING
16
NUT
|17
723-40-90101
VALVE ASS'Y,SUCTION AND SAFETY
|17
723-40-90100
VALVE ASS'Y,SUCTION AND SAFETY
17
SLEEVE
18
SLEEVE
19
POPPET
20
PISTON
|20
PISTON
21
SLEEVE
22
POPPET
23
UNION
24
PISTON
25
SPRING
26
SPRING
27
SPRING
28
SEAL
29
SEAL
30
709-25-11390
O-RING
31
O-RING
|31
O-RING
32
NUT
33
NUT
34
HOLDER
35
O-RING
|35
O-RING
36
SPRING
37
SEAL
|38
723-40-85100
VALVE ASS'Y,SUCTION
38
SLEEVE
39
VALVE
40
SPRING
41
SEAL
42
709-25-11390
O-RING
Выбрано товаров: 55
