Артикул
Название
Примечание
Количество
|1
723-48-16102
CONTROL VALVE
|1
723-48-16101
CONTROL VALVE
|1
723-48-16100
CONTROL VALVE
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1664-01A0 TO Y1664-15A0.
|1
BODY SUB ASS'Y
|1
BODY SUB ASS'Y
1
BLOCK,VALVE
|1
BLOCK,VALVE
2
SPOOL
3
SPOOL
4
SPOOL
|4
SPOOL
5
SPOOL
6
SPOOL
7
723-46-15130
PLUG
8
723-46-15140
PLUG
9
07002-10823
O-RING
10
708-7T-16460
BALL
11
723-46-15120
RETAINER
12
723-46-14110
SPRING
13
723-46-14170
SPRING
14
723-46-14131
SPRING
15
723-46-14161
SPRING
16
723-46-15250
SHIM
17
723-46-15110
CASE
18
07430-71380
O-RING
19
01252-30820
BOLT
20
723-46-15410
CASE
21
723-46-15420
RETAINER
22
723-46-15450
PLUG
23
07002-03034
O-RING
24
723-46-15440
SPRING
25
723-46-15430
PISTON
26
PLUG
|26
PLUG
27
723-46-15150
VALVE
28
723-46-14150
SPRING
Выбрано товаров: 37
