Запчасти Komatsu PC300LC-6 ОСНОВН. КЛАПАН (-АКТУАТОР) (7/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-47-18101

CONTROL VALVE

|1

723-47-18100

CONTROL VALVE

|1

723-47-16103

CONTROL VALVE

|1

723-47-16102

CONTROL VALVE

|1

723-47-16101

CONTROL VALVE

|$$6

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1662-01A0 TO Y1662-12A0.

|1

723-40-66100

VALVE ASS'Y

1

CASE

2

SEAT

3

708-8E-16160

PLUG

4

07002-11023

O-RING

5

SEAT

6

BALL

7

PLUG

|8

723-40-66200

VALVE ASS'Y

8

CASE

9

SEAT

10

SEAT

11

BALL

12

PLUG

13

01252-61050

BOLT

14

01643-51032

WASHER

|15

723-40-60101

VALVE ASS'Y

|15

723-40-60100

VALVE ASS'Y

15

SLEEVE

16

VALVE

17

PISTON

|17

PISTON

18

PISTON

19

SPRING

20

07000-12020

O-RING

21

07001-02020

RING,BACK-UP

22

709-25-11390

O-RING

23

SPRING

24

PLUG

25

O-RING

26

SEAL

|26

SEAL

27

O-RING
