Запчасти Komatsu PC300LC-6 ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№-798) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC300LC-6 - ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№-798) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
1
1
1
1
2
3
4
5
6
6
7
8
8
9
10
11
12
13
13
14
15
15
16
17
18
19
20
20
21
22
22
23
24
25
26
27
27
28
29
29
30
31
32
33
34
35
36
36
37
38
39
40
41
42
42
43
44
44
45
46
47
48
49
49
50
51
51
52

Артикул

Название

Примечание

Количество

|1

723-47-18100

CONTROL VALVE

|1

723-47-16103

CONTROL VALVE

|1

723-47-16102

CONTROL VALVE

|1

723-47-16101

CONTROL VALVE

|$$5

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1662-01A0 TO Y1662-12A0.

|1

BODY SUB ASS'Y

|1

BODY SUB ASS'Y

|1

BODY SUB ASS'Y

1

723-46-41110

VALVE

2

723-46-41120

VALVE

|3

723-46-40100

VALVE ASS'Y

3

SLEEVE

4

PISTON SUB ASS'Y

5

SPRING

6

SEAL

7

700-93-11320

O-RING

8

723-46-41950

RING

9

07002-13634

O-RING

|10

723-46-40300

VALVE ASS'Y

10

SLEEVE

11

PISTON

12

SPRING

13

SEAL

14

700-93-11320

O-RING

15

723-46-41950

RING

16

07002-13634

O-RING

|17

723-46-40601

VALVE ASS'Y

17

SLEEVE

18

PISTON SUB ASS'Y

19

SPRING

20

SEAL

21

700-93-11320

O-RING

22

723-46-41950

RING

23

07002-13634

O-RING

|24

723-46-43100

VALVE ASS'Y

24

SLEEVE

25

PISTON SUB ASS'Y

26

SPRING

27

SEAL

28

700-93-11320

O-RING

29

723-46-41950

RING

30

07002-13634

O-RING

|31

723-46-43200

VALVE ASS'Y

31

SLEEVE

32

VALVE SUB ASS'Y

33

SPRING

34

SEAL

35

700-93-11320

O-RING

36

723-46-41950

RING

37

07002-13634

O-RING

38

723-46-41980

RETAINER

|39

723-46-44100

VALVE ASS'Y

39

SLEEVE

40

PISTON SUB ASS'Y

41

SPRING

42

SEAL

43

700-93-11320

O-RING

44

723-46-41950

RING

45

07002-13634

O-RING

|46

723-46-45100

VALVE ASS'Y

46

SLEEVE

47

PISTON SUB ASS'Y

48

SPRING

49

SEAL

50

700-93-11320

O-RING

51

723-46-41950

RING

52

07002-13634

O-RING

Выбрано товаров: 67
