Запчасти Komatsu PC300LC-6 ОСНОВН. НАСОС (8/) (MIZUGURI СПЕЦ-Я.)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2H-00380

PUMP ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-41A0 T0 Y1600-51A0.

|1

708-2H-01380

PUMP SUB ASS'Y

1

708-2H-21860

BEARING,THRUST

2

708-2H-21820

GEAR,BEVEL

3

708-2H-21850

BUSHING

4

708-2H-21810

IMPELLER

5

04020-00820

PIN

6

708-2H-21830

GEAR,BEVEL

7

01010-61440

BOLT

8

01643-31445

WASHER

9

708-2H-21630

COVER

10

07000-A2105

O-RING

11

708-2H-05010

SHIM KIT

|11

SHIM¤ 0.1MM

|11

SHIM¤ 0.2MM

|11

SHIM¤ 0.5MM

12

01010-81235

BOLT

13

01643-31232

WASHER
