Запчасти Komatsu PC300LC-6 ОСНОВН. НАСОС (/9)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2H-00110

PUMP ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-09A0.

|1

708-2H-01110

PUMP SUB ASS'Y

1

708-2H-22120

SHAFT,REAR

2

708-1H-22150

BEARING

3

708-17-05010

WASHER KIT

|3

WASHER¤ 3.0MM

|3

WASHER¤ 3.1MM

|3

WASHER¤ 3.2MM

4

708-17-12780

RING

|5

708-2H-04150

BLOCK ASS'Y,REAR

5

BLOCK,CYLINDER

6

PLATE,VALVE

7

708-2H-23350

GUIDE,RETAINER

8

708-2H-23151

SPRING

9

708-2H-23130

SEAT

10

708-2H-23141

SEAT

11

04065-05820

RING

12

708-2H-23360

PIN

13

708-2H-23340

RETAINER,SHOE

14

708-2H-23311

PISTON SUB ASS'Y

|15

708-2H-04160

CRADLE ASS'Y

15

CRADLE

16

CAM,ROCKER

17

04020-01434

PIN

18

706-75-40340

BOLT

19

07000-B1009

O-RING
