Запчасти Komatsu PC300LC-5LC ТОПЛИВН. НАСОС ТОПЛИВН. СИСТЕМА

|$0

1294 802 H92

PUMP, FUEL

1

1241 260 H1

VALVE, OVERFLOW

2

1241 261 H1

WASHER, SEALING

3

1241 262 H1

PLUG, TIMING

4

1241 263 H1

WASHER, SEALING

5

1241 240 H1

LEVER, SHUTOFF VALVE

6

1241 264 H1

SPRING, SHUTOFF

7

1241 265 H1

HOUSING, RETURN SPRING

8

1241 266 H1

GASKET, FEED PUMP COVER

9

1241 267 H1

NUT, GEAR RETAINING

10

1241 268 H1

WASHER, LOCK

11

1241 275 H1

LEVER, CONTROL

12

1295 657 H1

SCREW, VENT

13

1295 658 H1

WASHER, SEALING

14

1295 659 H1

SCREW, VENT

15

1295 660 H1

WASHER, SEALING

16

1283 365 H1

SEAL, RECTANGULAR RING

17

1283 363 H1

COVER, FUEL PUMP

18

1296 799 H1

NUT, HEXAGON

19

1240 796 H1

LOCKWASHER

20

1296 800 H1

WASHER, FLAT

21

1307 345 H1

BOLT, THROTTLE

22

1241 233 H1

O-RING

23

1240 010 H1

ELBOW, MALE ADAPTER

24

1283 364 H1

ELBOW, MALE ADAPTER

25

1241 126 H1

HOSE, FLEXIBLE
