Запчасти Komatsu PC300LC-5LC ТУРБОНАГНЕТАТЕЛЬ ГОЛОВКА ЦИЛИНДРОВ

|$0

1294 839 H91

TURBOCHARGER ASSEMBLY

1

1294 843 H1

HOUSING, COMPRESSOR

2

1240 504 H1

DIFFUSER, TURBO

3

1240 489 H1

O-RING

4

1240 492 H1

NUT, HEX

5

1240 493 H1

SLINGER, OIL

6

1240 494 H1

COLLAR, THRUST

7

1294 841 H1

SHAFT & WHEEL

8

1294 842 H1

IMPELLER, TURBO

9

1246 480 H1

O-RING

10

1246 467 H1

BAFFLE, OIL

11

1246 465 H1

BOLT

12

1270 365 H1

BEARING, THRUST

13

1240 510 H1

RING, RETAINING

14

1240 490 H1

BEARING, TURBOCHARGER

15

1246 481 H1

BOLT

16

1240 487 H1

PLATE, CLAMPING

17

1294 982 H91

KIT, V-BAND CLAMP

18

1241 715 H1

NUT, HEX

19

1294 845 H1

HOUSING, TURBO BEARING

20

1240 496 H1

SHIELD, TURBO HEAT

21

1246 479 H1

O-RING

22

1294 844 H1

HOUSING, TURBINE

23

1240 506 H1

SEAL

24

NSS

DATAPLATE

25

1246 471 H1

SCREW, DRIVE

26

1278 296 H1

BOLT

27

1241 287 H1

GASKET, OIL DRAIN - TURBO

28

1241 249 H1

GASKET, TURBOCHARGER

|$29

1270 035 H91

KIT, TURBO REPAIR
