Запчасти Komatsu PC300LC-5LC ГИДР. НАСОС. ASSEMBLY ОСНОВН. НАСОС ASSEMBLY, ВАЛS И КОМПОНЕНТЫ УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

708-27-12711

SHAFT, MAIN HYDRAULIC PUMP FRONT

2

708-27-12721

SHAFT, MAIN HYDRAULIC PUMP REAR

3

708-27-12750

COLLAR

4

708-27-14410

GEAR

5

708-27-12621

SPACER

|$7

708-27-05020

SPACER KIT

6

NSS

SPACER, 0.0787 IN (2.0 mm)

6

NSS

SPACER, 0.0866 IN (2.2 mm)

6

NSS

SPACER, 0.0944 IN (2.4 mm)

6

NSS

SPACER, 0.1023 IN (2.6 mm)

6

NSS

SPACER, 0.1102 IN (2.8 mm)

7

708-27-12680

RING

8

708-27-12690

IMPELLER, MAIN HYDRAULIC PUMP

9

708-27-12860

PLATE

10

708-23-12350

SCREW

11

01643-30823

WASHER

12

708-27-12811

COUPLING

13

708-27-12820

RING

14

04000-01020

KEY

15

708-27-12730

BEARING

16

07000-02060

O-RING

|$23

708-27-05030

SPACER KIT

17

NSS

SPACER, 0.1496 IN (3.8 mm)

17

NSS

SPACER, 0.1535 IN (3.9 mm)

17

NSS

SPACER, 0.1574 IN (4.0 mm)

17

NSS

SPACER, 0.1614 IN (4.1 mm)

17

NSS

SPACER, 0.1653 IN (4.2 mm)

18

708-27-12960

SCREW

19

708-27-12880

BEARING

20

06000-51109

BEARING, THRUST

21

04000-00515

KEY

22

708-27-12780

PLATE

23

708-27-14490

BOLT
