Запчасти Komatsu PC300LC-5 КОНЕЧНАЯ ПЕРЕДАЧА И ЗВЕЗДОЧКА ХОД И НИЖН.CARRIAGE

|$0

207-27-00101

FINAL DRIVE ASSEMBLY

1

07002-02434

O-RING

2

07044-12412

PLUG

3

207-27-52310

BOLT

|$5

423-33-00020

SEAL ASSEMBLY, FLOATING

|$6

170-27-00113

RING ASSEMBLY, SEAL

5

NSS

RING, SEAL

|$8

195-27-00150

O-RING ASSEMBLY

6

NSS

O-RING

7

207-27-51291

COVER

8

207-27-51220

BEARING, BALL

9

207-27-52160

HUB

10

207-27-52350

O-RING

11

207-27-33222

SPROCKET

12

207-27-00110

SPACER KIT

|$16

NSS

SPACER - 0.128 IN. (3.25 MM)

|$17

NSS

SPACER - 0.130 IN. (3.30 MM)

|$18

NSS

SPACER - 0.132 IN. (3.35 MM)

|$19

NSS

SPACER - 0.134 IN. (3.40 MM)

|$20

NSS

SPACER - 0.136 IN. (3.45 MM)

|$21

NSS

SPACER - 0.138 IN. (3.50 MM)

|$22

NSS

SPACER - 0.140 IN. (3.55 MM)

13

207-27-52170

RETAINER

14

207-27-52180

CARRIER

15

207-27-52220

BEARING, ROLLER

16

207-27-52140

GEAR

17

207-27-51241

HOLDER

18

207-27-52240

PIN

19

01011-51805

BOLT

20

207-27-52270

SPACER

21

207-27-52131

GEAR

22

207-27-52110

SHAFT

23

207-27-52190

CARRIER

24

207-27-52120

GEAR

25

207-27-52250

PIN

26

01010-81060

BOLT

27

207-27-52320

BEARING, ROLLER

28

207-27-52260

HOLDER

29

20Y-27-11250

SPACER

30

207-27-52281

GEAR

31

04260-01905

BALL

32

207-27-52210

COVER

33

07049-01215

PLUG

34

01010-81030

BOLT

35

01643-31032

WASHER

36

207-27-51310

BOLT

37

207-27-52341

BOLT

38

01643-31845

WASHER

N/I

04020-01024

DOWEL, PIN

39

01010-82085

BOLT

40

01643-32060

WASHER
