Запчасти Komatsu PC300LC-5 CRANKING МОТОР - KW ЭЛЕКТРИКА

|$0

600-813-8810

MOTOR ASSEMBLY, CRANKING - 11 KW

1

SD1310-10000X0

YOKE

2

SD4141-26400X0

PACKING

3

SD2240-24150X0

BRACKET, REAR

4

SD1331-04300X0

BRUSH HOLDER ASSEMBLY

5

SD5250-02800X0

SPRING, BRUSH

6

SD5000-10500X0

SCREW

7

SD6414-04510X0

O-RING

8

SD3040-12100X0

PLATE

9

SD1320-07820X0

ARMATURE ASSEMBLY

10

SD6206-01250X0

BEARING, BALL

11

SD6206-01240X0

BEARING, BALL

12

SD8167-0719060

BOLT

13

SD2245-00820X0

CASE, GEAR

14

SD5031-05700X0

SHIM

15

SD2441-03200X0

SHAFT

16

SD2244-06902X0

HOLDER, CENTER

17

SD6410-01900X0

SEAL, OIL

18

SD6206-01260X0

BEARING, BALL

19

SD1361-04800X0

CLUTCH, PINION

20

SD3661-02000X0

STOPPER, PINION

21

SD5221-01200X0

HOOK

22

SD5058-04200X0

RING, RETAINING

23

SD5010-27430X0

BOLT

24

SD4141-26301X0

PACKING

25

SD1372-04200X0

LEVER

26

SD3600-17800X0

ROD

27

SD4223-05200X0

HOLDER, LEVER

28

SD5201-10100X0

COIL, SPRING

29

SD2407-02101X0

COLLAR

30

SD2244-06801X0

BRACKET, CENTER

31

SD2046-14000X9

CASE ASSEMBLY, PINION

32

SD2620-10500X9

BEARING

33

SD5010-26200X0

BOLT

34

SD1350-10800X9

SWITCH, CRANKING MOTOR SOLENOID

35

SD5010-27300X0

BOLT

36

SD0590-0012211

RELAY

37

SD1331-04300X9

BRUSH HOLDER ASSEMBLY - SERVICE PARTS

38

SD5250-02800X0

SPRING, BRUSH

39

SD2660-07400X6

BRUSH - FOR 1ST SERVICE ONLY

40

SD2660-07400X7

BRUSH - FROM 2ND SERVICE
