Запчасти Komatsu PC300LC-5 ГЕНЕРАТОР - A NON-HARDENED ШКИВ ОПЦ. ЭЛЕКТРИКА

|$0

600-821-6160

ALTERNATOR ASSEMBLY - 25 A WITH NON-HARDENED

1

KD1-09201-0530

BEARING, BALL

2

KD1-33926-0820

RETAINER

3

KD0-33100-1450

ROTOR

4

KD1-0416-04160

KEY, WOODRUFF

5

KD0-33923-0980

COLLAR

6

KD1-0055-06162

SCREW

7

KD0-35926-0060

RETAINER

8

KD1-33926-0750

RETAINER

9

KD1-0456-63057

BEARING, BALL

10

KD1-33926-0730

RETAINER

11

KD1-33923-0920

COLLAR

12

KD0-33902-0080

NUT

13

KD0-33902-0090

NUT

14

KD1-33943-0980

BUSHING, INSULATING

15

KD0-33943-1050

BUSHING, INSULATING

16

KD0-33710-3300

BRACKET, REAR

17

KD0-33784-0230

BAR, CONNECT

18

KD0-33780-0640

TERMINAL

19

KD0-0274-05102

BOLT

20

KD0-33719-0031

REGULATOR ASSEMBLY

21

KD1-33740-0450

BRUSH

22

KD0-33730-2560

RECTIFIER

23

KD0-33901-0790

BOLT

24

KD0-0275-06802

BOLT

25

KD0-33200-1410

STATOR

26

KD0-33311-0470

BRACKET

26

KD0-33311-0510

BRACKET

27

KD1-33421-0590

FAN

28

KD0-35411-0391

PULLEY - NON-HARDENED

29

KD0-0280-16022

NUT

30

KD1-33951-0610

PACKING
