Запчасти Komatsu PC300LC-5 ВОДЯНАЯ ПОМПА И КРЕПЛЕНИЕ СТАНДАРТН. ТРУБКИ КОНДИЦИОНЕРА - ОБОГРЕВ.

|$0

6221-61-1101

PUMP ASSEMBLY, WATER - WITH NON-HARDENED PULLEY

|$1

6221-61-1501

PUMP ASSEMBLY, WATER - WITH HARDENED PULLEY

1

NSS

BODY

2

6206-61-1341

SHAFT

2

6206-61-1340

SHAFT

3

6221-61-1310

IMPELLER

4

6221-61-1520

SEAL, WATER

5

6221-61-1120

COVER

6

6221-61-1190

GASKET

7

01236-40820

SCREW

8

01435-20820

BOLT

9

01435-20850

BOLT

10

6221-61-1410

PULLEY, NON-HARDENED

10

6221-61-1450

PULLEY, HARDENED - SANDY AND DUSTY SPECIFICATION

11

6221-61-1890

GASKET

12

01435-01045

BOLT

13

01435-01065

BOLT

16

01435-00835

BOLT

17

07042-00415

PLUG

18

6222-11-6510

CONNECTOR

19

6221-11-6890

GASKET

20

01435-01080

BOLT

21

6221-61-6310

CONNECTOR

22

07000-03028

O-RING

23

01435-20850

BOLT

24

09483-47008

HOSE

25

07281-00489

CLAMP

26

6222-11-6530

TUBE

27

07000-03045

O-RING

28

6222-11-6520

CONNECTOR

29

6222-11-6890

GASKET

30

01435-20880

BOLT

31

600-421-6410

THERMOSTAT, ENGINE

32

6221-61-6710

CONNECTOR

33

6138-11-6810

GASKET

34

01435-21045

BOLT

35

01436-21020

BOLT

36

01435-01055

BOLT

37

6131-12-4570

SPACER

38

6221-61-6510

TUBE

39

07214-50510

CONNECTOR

40

7861-92-3320

SENSOR, WATER TEMPERATURE

41

09482-20000

VALVE, HEATER SHUTOFF

42

6222-61-3810

BELT, WATER PUMP
