Запчасти Komatsu PC300LC-5 ТОПЛ. НАСОС РЕГУЛЯТОР - ЗАДН. ТОПЛИВН. СИСТЕМА

1

ND190890-0130

COVER

2

ND091031-0150

NUT, CAP

3

ND091006-0150

SCREW, ADJUSTING

4

ND090944-0310

BUSHING

5

ND090989-0010

SHAFT, LEVER SUPPORT

6

ND090991-0010

PLUG

7

ND090560-0200

CAPSULE, FULL STOP

8

ND090923-0060

NUT

9

ND090892-0160

BUSHING, LEVER

10

ND949140-5760

O-RING

|$15

ND090910-1390

ADAPTER ASSEMBLY

11

ND090911-0010

SCREW, ADAPTER

12

ND090919-0010

ADAPTER

13

ND090918-2250

SPRING, GOVERNOR

14

ND090894-0010

E-RING

15

ND949013-3880

WASHER - 0.004 IN. (0.10 MM)

|$21

ND949013-4040

WASHER - 0.008 IN. (0.20 MM)

|$22

ND949013-4020

WASHER - 0.010 IN. (0.25 MM)

|$23

ND949013-4030

WASHER - 0.020 IN. (0.50 MM)

|$24

ND949013-7880

WASHER - 0.039 IN. (1.00 MM)

16

ND090923-0011

NUT, ADAPTER LOCK

17

ND949047-1760

BOLT

18

ND949047-1750

BOLT

19

ND949150-2690

SEAL, OIL

20

ND091071-1420

LEVER, ADJUSTING

21

ND091071-4110

LEVER, ADJUSTING

22

ND949047-1190

BOLT

23

ND091094-0060

CAP, LEVER

24

ND91418-06161

BOLT

24

ND914180-6161

BOLT

25

ND091050-0410

PLATE, COVER

26

ND949047-2700

BOLT

27

ND91418-06201

BOLT

28

ND090241-0010

WASHER

29

ND091031-0030

NUT, CAP

30

ND949062-1270

PACKING, RUBBER PLATE

31

ND090944-0440

BUSHING

32

ND949013-8210

WASHER - 0.012 IN. (0.30 MM)

|$43

ND949013-8220

WASHER - 0.023 IN. (0.60 MM)

|$44

ND949013-8230

WASHER - 0.035 IN. (0.90 MM)

33

ND949050-3390

NUT

34

ND949018-1020

WASHER

35

ND949140-5740

O-RING
