Запчасти Komatsu PC300LC-5 ТОПЛ. НАСОС РЕГУЛЯТОР - ПЕРЕДН. ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu PC300LC-5 - ТОПЛ. НАСОС РЕГУЛЯТОР - ПЕРЕДН. ТОПЛИВН. СИСТЕМА
34
21
20
6
19
9
18
24
27
19
4
2
28
8
29
33
22
32
5
32
17
23
16
15
14
30
13
32
12
11
31
32
26
1
7
10
3
25

Артикул

Название

Примечание

Количество

|$1

ND190800-2580

GOVERNOR ASSEMBLY, FUEL INJECTION PUMP

1

ND090810-0540

HOUSING

2

ND090878-0260

PLATE

3

ND091024-0031

SCREW, ADJUSTING

4

ND090901-0150

LEVER, TENSION

5

ND090930-0490

LEVER, CONTROL

6

ND090894-0010

E-RING

7

ND948053-0051

NUT

8

ND091046-0010

SLIDER, SUPPORTING

9

ND090970-0350

SHACKLE

10

ND949130-0050

KEY, WOODRUFF

11

ND090940-0520

FLYWEIGHT

12

ND949015-0500

WASHER, SPRING

13

ND090844-0010

NUT

14

ND090860-0200

SLEEVE ASSEMBLY, GOVERNOR

15

ND090868-0040

PLATE, THRUST

16

ND90567-30000

RING, SNAP

17

ND949013-4090

WASHER - 0.004 IN. (0.1 MM)

|$19

ND949013-4060

WASHER - 0.008 IN. (0.2 MM)

|$20

ND949013-4070

WASHER - 0.012 IN. (0.3 MM)

|$21

ND949013-4080

WASHER - 0.016 IN. (0.4 MM)

|$22

ND949013-4100

WASHER - 0.039 IN. (1.0 MM)

18

ND090880-0110

LEVER, SWIVEL

19

ND949071-0090

WASHER, SNAP

20

ND090992-0420

SPRING, CONTROL

21

ND090993-0280

SPRING, START

22

ND090224-0140

PLUG, SCREW

23

ND949018-1550

WASHER

24

ND949130-0030

KEY, WOODRUFF

25

ND090119-0040

GASKET, BODY

26

ND090823-0230

GASKET

27

ND090245-0230

SCREW

28

ND090222-0120

WASHER

29

ND949044-4000

BOLT

30

ND949044-4070

BOLT

31

ND949044-4010

BOLT

32

ND949013-6520

WASHER - 0.039 IN. (1.0 MM)

33

ND949044-4060

BOLT

Выбрано товаров: 38
