Запчасти Komatsu PC300LC-5 ТОПЛ. НАСОС - НАСОС ТОПЛИВН. СИСТЕМА

|$0

6222-71-1120

PUMP ASSEMBLY, FUEL INJECTION

|$1

ND090100-8380

PUMP ASSEMBLY, FUEL INJECTION

1

ND090110-4350

HOUSING ASSEMBLY

2

ND949043-0010

STUD

3

ND090130-0310

HOLDER, DELIVERY VALVE

4

ND090136-0730

SPRING, DELIVERY VALVE

5

ND949140-2570

O-RING

6

ND090140-2020

VALVE, DELIVERY

7

ND090150-4660

ELEMENT, PUMP

8

ND090160-0150

SLEEVE, CONTROL

9

ND090212-0471

RACK, CONTROL

10

ND090163-0160

SEAT, UPPER SPRING

11

ND090164-0250

SPRING, PLUNGER

12

ND090165-0150

SEAT, LOWER SPRING

13

ND090170-0320

TAPPET

14

ND090438-0390

SHIM, ELEMENT HOLDER - 0.069 IN. (1.75 MM)

|$16

ND090438-0400

SHIM, ELEMENT HOLDER - 0.071 IN. (1.80 MM)

|$17

ND090438-0410

SHIM, ELEMENT HOLDER - 0.073 IN. (1.85 MM)

|$18

ND090438-0420

SHIM, ELEMENT HOLDER - 0.075 IN. (1.90 MM)

|$19

ND090438-0430

SHIM, ELEMENT HOLDER - 0.077 IN. (1.95 MM)

|$20

ND090438-0440

SHIM, ELEMENT HOLDER - 0.079 IN. (2.00 MM)

|$21

ND090438-0450

SHIM, ELEMENT HOLDER - 0.081 IN. (2.05 MM)

|$22

ND090438-0460

SHIM, ELEMENT HOLDER - 0.083 IN. (2.10 MM)

|$23

ND090438-0470

SHIM, ELEMENT HOLDER - 0.085 IN. (2.15 MM)

|$24

ND090438-0480

SHIM, ELEMENT HOLDER - 0.087 IN. (2.20 MM)

|$25

ND090438-0490

SHIM, ELEMENT HOLDER - 0.089 IN. (2.25 MM)

|$26

ND090438-0500

SHIM, ELEMENT HOLDER - 0.090 IN. (2.30 MM)

|$27

ND090438-0510

SHIM, ELEMENT HOLDER - 0.093 IN. (2.35 MM)

|$28

ND090438-0520

SHIM, ELEMENT HOLDER - 0.094 IN. (2.40 MM)

15

ND949013-5880

WASHER, PLATE

16

ND090206-0070

O-RING, BEARING COVER

17

ND090139-0020

O-RING

18

ND949018-1730

WASHER, COPPER

19

ND090191-1240

CAMSHAFT

20

ND949101-0140

BEARING, ROLLER

21

ND090193-0050

RING, ADJUST

22

ND090194-0070

PLATE - 0.004 IN. (0.10 MM)

|$37

ND090194-0080

PLATE - 0.006 IN. (0.15 MM)

|$38

ND090194-0090

PLATE - 0.012 IN. (0.30 MM)

|$39

ND090194-0100

PLATE - 0.020 IN. (0.50 MM)

|$40

ND090194-0340

PLATE - 0.005 IN. (0.12 MM)

|$41

ND090194-0350

PLATE - 0.006 IN. (0.14 MM)

|$42

ND090194-0360

PLATE - 0.007 IN. (0.18 MM)

23

ND949150-1420

SEAL, OIL

24

ND090201-0501

COVER, BEARING

25

ND91418-06201

BOLT

26

ND090433-0020

RETAINER, BEARING

27

ND090361-0180

BEARING, CENTER

28

ND090248-0010

WASHER

29

ND090215-0060

SCREW

30

ND090317-0140

PLUG, SCREW

31

ND090193-0060

RING, ADJUST

32

ND090222-0070

WASHER, UNION

33

ND949180-0020

SCREW

34

ND949140-0380

O-RING

35

ND090244-0160

SCREW

36

ND949101-0130

BEARING, ROLLER

37

ND090194-0300

PLATE - 0.004 IN. (0.10 MM)

|$58

ND090194-0370

PLATE - 0.005 IN. (0.12 MM)

|$59

ND090194-0380

PLATE - 0.006 IN. (0.14 MM)

|$60

ND090194-0310

PLATE - 0.006 IN. (0.15 MM)

|$61

ND090194-0390

PLATE - 0.007 IN. (0.18 MM)

|$62

ND090194-0320

PLATE - 0.012 IN. (0.30 MM)

|$63

ND090194-0330

PLATE - 0.020 IN. (0.50 MM)

38

ND090114-0110

BUSHING

39

ND090367-0040

BUSHING

40

ND949018-0350

WASHER

41

ND090018-0330

COVER

42

ND949050-3400

NUT

43

ND949015-0730

WASHER, SPRING

44

ND90458-05750

KEY, WOODRUFF

44

04040-00519

KEY, WOODRUFF

45

ND949018-1550

WASHER

46

ND090222-0070

WASHER, UNION

47

ND090310-0080

VALVE, OVERFLOW

48

ND949140-3690

O-RING
