Запчасти Komatsu PC300LC-5 ТОПЛИВН. ВПРЫСК И СЛИВНАЯ ТРУБКА ТОПЛИВН. СИСТЕМА

|$0

6222-11-3100

INJECTOR ASSEMBLY, FUEL

|$1

ND093100-4240

HOLDER ASSEMBLY

1

ND093110-4240

BODY, INJECTOR

2

ND093121-0480

PIN, PRESSURE

3

ND093127-0410

SPRING, PRESSURE

4

ND093164-1020

NUT, RETAINING

5

ND093175-2560

SHIM - 0.028 IN. (0.700 MM)

|$7

ND093175-2570

SHIM - 0.030 IN. (0.750 MM)

|$8

ND093175-2580

SHIM - 0.031 IN. (0.800 MM)

|$9

ND093175-2590

SHIM - 0.033 IN. (0.850 MM)

|$10

ND093175-2600

SHIM - 0.035 IN. (0.900 MM)

|$11

ND093175-2530

SHIM - 0.037 IN. (0.950 MM)

|$12

ND093175-2610

SHIM - 0.038 IN. (0.975 MM)

|$13

ND093175-2180

SHIM - 0.039 IN. (1.000 MM)

|$14

ND093175-2620

SHIM - 0.040 IN. (1.025 MM)

|$15

ND093175-2190

SHIM - 0.041 IN. (1.050 MM)

|$16

ND093175-2630

SHIM - 0.042 IN. (1.075 MM)

|$17

ND093175-2200

SHIM - 0.043 IN. (1.100 MM)

|$18

ND093175-2640

SHIM - 0.044 IN. (1.125 MM)

|$19

ND093175-2210

SHIM - 0.045 IN. (1.150 MM)

|$20

ND093175-2650

SHIM - 0.046 IN. (1.175 MM)

|$21

ND093175-2220

SHIM - 0.047 IN. (1.200 MM)

|$22

ND093175-2660

SHIM - 0.048 IN. (1.225 MM)

|$23

ND093175-2420

SHIM - 0.050 IN. (1.275 MM)

|$24

ND093175-2240

SHIM - 0.051 IN. (1.300 MM)

|$25

ND093175-2430

SHIM - 0.052 IN. (1.325 MM)

|$26

ND093175-2250

SHIM - 0.053 IN. (1.350 MM)

|$27

ND093175-2440

SHIM - 0.054 IN. (1.375 MM)

|$28

ND093175-2260

SHIM - 0.055 IN. (1.400 MM)

|$29

ND093175-2450

SHIM - 0.056 IN. (1.425 MM)

|$30

ND093175-2270

SHIM - 0.057 IN. (1.450 MM)

|$31

ND093175-2460

SHIM - 0.058 IN. (1.475 MM)

|$32

ND093175-2280

SHIM - 0.059 IN. (1.500 MM)

|$33

ND093175-2290

SHIM - 0.061 IN. (1.550 MM)

|$34

ND093175-2300

SHIM - 0.062 IN. (1.600 MM)

|$35

ND093175-2310

SHIM - 0.065 IN. (1.650 MM)

|$36

ND093175-2320

SHIM - 0.067 IN. (1.700 MM)

|$37

ND093175-2330

SHIM - 0.069 IN. (1.750 MM)

|$38

ND093175-2340

SHIM - 0.071 IN. (1.800 MM)

6

ND093221-0150

PACKING

7

ND094082-3610

PIN, STRAIGHT

8

6222-11-3120

NOZZLE, FUEL INJECTOR

9

6204-11-3850

SEAL, DUST

10

6204-11-3880

GASKET

11

6204-11-3810

HOLDER

12

01435-01040

BOLT

13

6204-11-3830

WASHER

14

600-815-2770

PLUG, GLOW

15

6221-81-4110

LEAD

16

6204-71-9120

HOSE, SPILL

16

6142-71-5330

HOSE, SPILL

17

6204-71-5581

CAP, HOSE

17

6207-71-5580

CAP, HOSE

18

07285-00100

CLIP

18

07285-00080

CLIP

19

07285-00100

CLIP

19

07285-00080

CLIP

|$68

6204-71-9120

HOSE, SPILL

|$69

07285-00100

CLIP

|$81

6204-71-5581

CAP, HOSE

|$82

07285-00100

CLIP
