Запчасти Komatsu PC300LC-5 КОЛЕНВАЛ БЛОК ЦИЛИНДРОВ

|$0

6222-31-1100

CRANKSHAFT ASSEMBLY, ENGINE

1

NSS

CRANKSHAFT

2

6221-31-1120

GEAR

3

6136-31-1140

KEY

4

6221-31-1130

GEAR, PUMP DRIVE

5

6222-31-1410

PULLEY, NON-HARDENED

5

6222-31-1450

PULLEY, HARDENED - SANDY AND DUSTY SPECIFICATION

6

6136-31-1420

COLLAR

7

6136-31-1431

PLATE

8

01050-31845

BOLT

9

6222-31-8110

DAMPER, VIBRATION

10

6222-91-1510

PULLEY, NON-HARDENED

10

6222-91-1550

PULLEY, HARDENED - SANDY AND DUSTY SPECIFICATION

11

01435-01035

BOLT

|$14

6221-21-8010

BEARING ASSEMBLY, MAIN - STANDARD

12

NSS

BEARING, UPPER

13

NSS

BEARING, LOWER

|$17

6221-29-8010

BEARING ASSEMBLY, MAIN - 0.009 IN. (0.25 MM) U/S

12

NSS

BEARING, UPPER

13

NSS

BEARING, LOWER

|$20

6221-28-8010

BEARING ASSEMBLY, MAIN - 0.020 IN. (0.50 MM) U/S

12

NSS

BEARING, UPPER

13

NSS

BEARING, LOWER

|$23

6221-27-8010

BEARING ASSEMBLY, MAIN - 0.030 IN. (0.75 MM) U/S

12

NSS

BEARING, UPPER

13

NSS

BEARING, LOWER

|$26

6221-26-8010

BEARING ASSEMBLY, MAIN - 0.039 IN. (1.00 MM) U/S

12

NSS

BEARING, UPPER

13

NSS

BEARING, LOWER

14

6221-21-8050

BEARING ASSEMBLY, THRUST - STANDARD

|$30

6221-29-8050

BEARING ASSEMBLY, THRUST - 0.009 IN. (0.25 MM) O/S

|$31

6221-28-8050

BEARING ASSEMBLY, THRUST - 0.020 IN. (0.50 MM) O/S

|$32

6221-27-8050

BEARING ASSEMBLY, THRUST - 0.030 IN. (0.75 MM) O/S

|$33

6221-26-8050

BEARING ASSEMBLY, THRUST - 0.039 IN. (1.00 MM) O/S
