Запчасти Komatsu PC300LC-5 БЛОК ЦИЛИНДРОВ БЛОК ЦИЛИНДРОВ

|$0

6222-21-1101

BLOCK ASSEMBLY, CYLINDER

1

NSS

BLOCK, CYLINDER

2

6221-21-1410

BUSHING, CAMSHAFT

3

04025-00408

PIN, SPRING

4

6222-29-1210

CAP, MAIN BEARING

5

6222-29-1250

CAP, MAIN BEARING

6

04020-00514

PIN, DOWEL

7

04025-00408

PIN, SPRING

8

6221-21-1710

BOLT, MAIN BEARING CAP

9

6130-32-1361

WASHER

10

07046-42216

PLUG

11

6136-21-1911

PIN, DOWEL

12

04025-00512

PIN, SPRING

13

04020-01228

PIN, DOWEL

14

07040-11209

PLUG

15

07005-01212

GASKET

16

07043-70108

PLUG

17

07040-11007

PLUG

18

07005-01012

GASKET

19

07043-70211

PLUG

20

07046-43016

PLUG, EXPANSION

21

07046-46520

PLUG, EXPANSION

22

07046-43513

PLUG, EXPANSION

23

6221-21-1790

BUSHING

24

6222-21-2210

LINER, CYLINDER (S)

|$25

6222-21-2220

LINER, CYLINDER (M)

|$26

6222-21-2230

LINER, CYLINDER (L)

25

07046-42010

PLUG, EXPANSION

26

6221-21-5511

GUIDE, OIL GAUGE

27

01435-01016

BOLT

28

6136-21-5390

GAUGE, ENGINE OIL LEVEL

29

6221-21-7210

COVER

30

6136-21-7811

GASKET

31

01435-21025

BOLT

37

6221-21-9280

PLATE

38

07042-00415

PLUG

39

6221-21-7680

GASKET

39

6221-21-7670

GASKET

40

01435-01035

BOLT

41

6221-61-1910

BRACKET, WATER PUMP

42

01435-21020

BOLT
