Запчасти Komatsu PC300LC-5 ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ

|$0

6221-11-1101

CYLINDER HEAD ASSEMBLY, WITHOUT VALVES

1

NSS

HEAD, ENGINE CYLINDER

2

07046-41810

PLUG

3

6221-11-1330

SEAT, INTAKE VALVE - STD

|$4

6221-19-1330

SEAT, INTAKE VALVE 0.010 IN. (0.25 MM) O/S

|$5

6221-18-1330

SEAT, INTAKE VALVE 0.020 IN. (0.50 MM) O/S

|$6

6221-17-1330

SEAT, INTAKE VALVE 0.030 IN. (0.75 MM) O/S

|$7

6221-16-1330

SEAT, INTAKE VALVE 0.039 IN. (1.00 MM) O/S

4

6221-11-1320

SEAT, EXHAUST VALVE - STD

|$9

6221-19-1320

SEAT, EXHAUST VALVE 0.010 IN. (0.25 MM) O/S

|$10

6221-18-1320

SEAT, EXHAUST VALVE 0.020 IN. (0.50 MM) O/S

|$11

6221-17-1320

SEAT, EXHAUST VALVE 0.030 IN. (0.75 MM) O/S

|$12

6221-16-1320

SEAT, EXHAUST VALVE 0.039 IN. (1.00 MM) O/S

5

6221-19-1311

GUIDE, VALVE

6

07046-42816

PLUG

7

07046-44016

PLUG

8

07043-70108

PLUG

9

6221-41-4110

VALVE, INTAKE

10

6221-41-4210

VALVE, EXHAUST

11

6221-41-4410

SPRING, VALVE

12

6221-41-4510

GUIDE, SPRING

13

6136-42-4520

COLLET

14

6140-41-4540

SEAL, EXHAUST VALVE

15

6221-11-1811

GASKET, HEAD

16

6221-11-1610

BOLT, HEAD

17

6221-11-1911

HANGER, FRONT

18

6136-11-1920

HANGER, REAR

19

6221-11-1930

HANGER, REAR

20

01435-01020

BOLT

21

01435-01035

BOLT

22

6162-63-3910

SPACER
