Запчасти Komatsu PC300LC-5 ГИДР. НАСОС. ASSEMBLY ОСНОВН. НАСОС ASSEMBLY - ВАЛS И КОМПОНЕНТЫ УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

708-27-12711

SHAFT, MAIN HYDRAULIC PUMP - FRONT

2

708-27-12721

SHAFT, MAIN HYDRAULIC PUMP - REAR

3

708-27-12750

COLLAR

4

708-27-14410

GEAR

5

708-27-12621

SPACER

6

708-27-05020

SPACER KIT

|$8

NSS

SPACER - 0.079 IN. (2.0 MM)

|$9

NSS

SPACER - 0.087 IN. (2.2 MM)

|$10

NSS

SPACER - 0.094 IN. (2.4 MM)

|$11

NSS

SPACER - 0.102 IN. (2.6 MM)

|$12

NSS

SPACER - 0.110 IN. (2.8 MM)

7

708-27-12680

RING

8

708-27-12690

IMPELLER, MAIN HYDRAULIC PUMP

9

708-27-12860

PLATE

10

708-23-12350

SCREW

11

01643-30823

WASHER

12

708-27-12811

COUPLING

13

708-27-12820

RING

14

04000-01020

KEY

15

708-27-12730

BEARING

16

07000-02060

O-RING

17

708-27-05030

SPACER KIT

|$24

NSS

SPACER - 0.150 IN. (3.8 MM)

|$25

NSS

SPACER - 0.154 IN. (3.9 MM)

|$26

NSS

SPACER - 0.157 IN. (4.0 MM)

|$27

NSS

SPACER - 0.161 IN. (4.1 MM)

|$28

NSS

SPACER - 0.165 IN. (4.2 MM)

18

708-27-12960

SCREW

19

708-27-12880

BEARING

20

06000-51109

BEARING, THRUST

21

04000-00515

KEY

22

708-27-12780

PLATE

23

708-27-14490

BOLT
