Запчасти Komatsu PC300LC-5 ГИДР. НАСОС. ASSEMBLY ОСНОВН. НАСОС ASSEMBLY - ПЕРЕДН. CRADLE И КОМПОНЕНТЫ УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$2

708-27-00031

CRADLE ASSEMBLY, MAIN PUMP

|$3

708-27-00450

CRADLE SUB-ASSEMBLY, MAIN PUMP

1

NSS

CRADLE, FRONT

2

NSS

PLUG

3

708-27-13411

CAM, MAIN PUMP ROCKER

4

01010-81450

BOLT

5

20D-14-11510

WASHER

6

708-27-12330

PLATE

7

04020-00820

PIN, DOWEL

8

708-27-12340

SCREW

9

01643-30823

WASHER

10

708-27-12350

STOPPER

11

04020-00820

PIN, DOWEL

12

706-75-42270

SCREW

13

708-27-14121

SLIDER

14

708-27-13314

PISTON, SUB-ASSEMBLY

15

708-27-13342

RETAINER, SHOE

|$19

708-27-00431

BLOCK ASSEMBLY, CYLINDER FRONT

16

708-27-13112

BLOCK

17

708-27-13611

VALVE PLATE, FRONT

18

708-27-05051

SPACER KIT

|$23

NSS

SPACER - 0.533 IN. (13.54 MM)

|$24

NSS

SPACER - 0.534 IN. (13.56 MM)

|$25

NSS

SPACER - 0.534 IN. (13.57 MM)

19

708-27-13420

RETAINER

20

708-27-13480

SCREW

21

01643-30823

WASHER

22

708-27-13120

WASHER

23

708-27-13140

SPRING

24

708-27-13130

RETAINER

25

708-27-13150

RING, SNAP
