Запчасти Komatsu PC300HD-8 A-AA ТУРБОНАГНЕТАТЕЛЬ ORIGINAL RELEASE ДВИГАТЕЛЬ

|$0

6745-82-8010

TURBOCHARGER

|$1

NSS

TURBOCHARGER

1

NSS

BAFFLE, TURBOCHARGER NOISE

2

6736-81-8370

BEARING, TURBOCHARGER

3

6731-82-8210

NUT, LOCK

4

6733-81-8650

WASHER, PLAIN

5

6736-81-8480

BOLT

6

6736-81-8430

SHIELD, TURBOCHARGER HEAT

7

NSS

SHAFT & WHEEL

8

6733-81-8360

RING, RETAINING

9

NSS

DATAPLATE

10

NSS

BAFFLE, OIL

11

6732-81-8140

COUPLING, ELBOW HOSE

12

NSS

END, ADJUSTING LINK

13

6743-82-8610

NUT, HEXAGON FLANGE

14

6733-81-8370

RING, RETAINING

15

6733-81-8460

SEAL, O RING

16

6743-82-8130

BOLT (M8-1.25x20)

17

NSS

PLATE, OIL SEAL

18

NSS

SLINGER, OIL

19

NSS

ACTUATOR, TURBOCHARGER

20

6733-81-6850

SPACER, MOUNTING

21

6735-81-6810

SPACER, MOUNTING

22

6735-82-8220

BEARING, TURBOCHARGER THRUST

23

6735-81-8620

COLLAR, THRUST

24

6742-01-5569

BOLT

25

NSS

IMPELLER, TURBOCHARGER COMPRESSOR

26

6733-81-8480

PIN, ROLL

27

NSS

HOUSING, TURBOCHARGER BEARING

28

NSS

PLATE, CLAMPING

29

6735-81-8370

BOLT

30

NSS

HOUSING, TURBINE

31

6735-81-8310

RING, RETAINING

32

6735-81-8490

BRACKET, ACTUATOR

33

6742-01-5565

GASKET, ADAPTER

34

6742-01-5564

CLAMP, HOSE

35

NSS

CONNECTION, ADAPTER

36

6742-01-5566

HOSE, PLAIN

37

NSS

HOUSING, COMPRESSOR

38

6736-81-8440

SEAL, SPLIT RING

39

6736-81-8320

SEAL, SPLIT RING

40

6736-81-8380

BOLT (M8-1.25x12)

41

6736-81-8360

RING, RETAINING

42

6743-82-8140

RING, RETAINING
