Запчасти Komatsu PC300HD-7L U-A ТАБЛИЧКИ заводской номер A8-A87 МАРКИРОВКА

1

20Y-00-31170

PLATE, EMERGENCY EXIT DECAL

2

09685-00002

PLATE, OPERATING, LOCK LEVER

3

205-00-73360

PLATE, OPERATING, HYD GAUGE

4

09690-M0063

PLATE, MARK, KOMATSU STAMP

5

09690-P0630

PLATE, MARK, BATTERY BOX

6

09133-23000

PLATE, SAFETY

7

09134-A1681

PLATE, CAUTION

8

09653-03001

PLATE, SAFETY WARNING HOT LIQUID

9

09657-03003

PLATE, SAFETY, TRACK ADJUSTMENT

10

09659-53000

PLATE, SAFETY WARNING EXPLOSION

11

09667-03001

PLATE, SAFETY, ROTATION PART

12

09803-03000

PLATE, CAUTION, WINDOW LOCK

13

09805-23000

PLATE, SAFET, FENDER AND HOOD

14

09805-13000

PLATE, SAFETY, HOOD

15

09808-03000

PLATE, SAFETY, BATTERY CABLE

16

22U-00-21290

PLATE, WARNING RIGHT SIDE WINDOW

17

09669-0000E

PLATE, CAUTION

18

207-00-71151

PLATE, SERVICE, LUB CHART

19

09601-10000

PLATE, NAME SERIAL

20

04418-13060

SCREW

21

09963-03001

TAG

22

203-00-51170

SEAT, NON-SLIP DECAL

23

154-54-23260

SEAT, NON-SLIP DECAL

24

207-00-A8120

MARK PLATE, 300 HD MODEL NUMBER

25

207-00-71460

PLATE, FUSE BOX FECAL

26

207-00-71470

PLATE, SWITCH POSITION DECAL

27

20Y-00-31350

PLATE, LOCK, FRONT LOWER WINDOW
