Запчасти Komatsu PC300HD-7L P-7A МОТОР ХОДА ВЕДУЩ. ВАЛ заводской номер A8- НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

1

706-8J-41610

SHAFT, DRIVE

2

706-8J-41010

BEARING

3

706-77-42890

BEARING

4

706-8J-41810

RETAINER

5

706-8J-41660

SPACER KIT

|$6

NSS

SPACER, 2.1 MM

|$7

NSS

SPACER, 2.3 MM

|$8

NSS

SPACER, 2.5 MM

|$9

NSS

SPACER, 2.7 MM

|$10

NSS

SPACER, 1.9 MM

6

04064-06525

RING

7

706-8J-41620

SEAL, OIL

8

706-8J-41820

SPACER

9

04065-09030

RING, SNAP

10

706-8J-41280

SHAFT, CENTER

11

706-8J-41270

RING, CENTER

12

706-8J-41290

SPRING

13

706-8J-41260

RETAINER

14

708-23-12350

SCREW

15

706-8J-41161

PISTON SUB ASSEMBLY

16

706-7K-91340

PLATE

17

706-7K-91350

DISC

18

706-8J-91110

PISTON, BRAKE

19

07000-15230

O-RING

20

07001-05230

RING, BACK-UP

21

708-8H-15220

O-RING

22

706-8J-91120

RING, BACK-UP

23

706-8J-91130

SPRING
