Запчасти Komatsu PC300HD-7L K-A КАБИНА ПЕРЕДН. ОКНА заводской номер A88- OPERATOR ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$1

208-53-00020

FRONT WINDOW ASSEMBLY

1

NSS

FRAME

2

20Y-54-51522

GLASS

3

20Y-54-51531

SEAL

4

20Y-54-51551

SEAL

5

22B-54-15411

LOCK ASSEMBLY

6

22B-54-15440

CASE

7

22B-54-15470

KNOB

8

22B-54-15421

LOCK ASSEMBLY

9

22B-54-15450

CASE

10

22B-54-15480

KNOB

11

01435-40812

BOLT

12

20Y-54-52621

ROLLER

13

20Y-54-52681

ROLLER

14

208-53-12690

PIN

15

20Y-54-14590

HANDLE

16

01023-10616

SCREW

17

208-53-12630

BRACKET

18

208-53-12830

BRACKET

19

01245-00816

SCREW

20

20Y-54-51670

STOPPER

21

20Y-54-51680

STOPPER

22

01252-80616

BOLT

23

01643-70623

WASHER

24

208-53-11560

BLOCK

25

01245-00816

SCREW

26

01643-70823

WASHER

27

20Y-54-51633

BLOCK

28

20Y-54-52192

BLOCK

29

01252-80616

BOLT

30

01641-50608

WASHER

31

22B-54-15621

STOPPER

32

22B-54-15432

STRIKER

33

01435-40616

BOLT

34

21J-06-12440

SWITCH

35

01583-11811

NUT

36

20Y-54-51880

BRACKET

37

01435-40616

BOLT

38

20Y-54-11611

STOPPER

39

01580-11008

NUT

40

20Y-54-52491

PLATE

41

01435-40616

BOLT

42

20Y-54-51621

STRIKER

43

208-53-11540

SEAL

44

20Y-54-51591

SPRING ASSEMBLY

45

01435-00616

BOLT

46

20Y-54-51640

HOLDER

47

20Y-54-51420

SEAL

48

208-53-11470

BRACKET

49

01435-40616

BOLT
