Запчасти Komatsu PC300HD-7L A-AA7 БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6743-22-1100

BLOCK ASSEMBLY, CYLINDER

1

NSS

BLOCK, CYLINDER

2

6742-01-1360

PLUG, EXPANSION

3

6742-01-1370

PLUG, EXPANSION

4

6732-21-1810

PLUG, EXPANSION

5

6742-01-5160

BUSHING

6

6742-01-1420

PLUG, EXPANSION

7

6741-21-1140

BOLT (M14-2.00x135)

8

6741-21-1130

CAP, MAIN BEARING

|$9

6743-01-1220

KIT, CYLINDER BLOCK HARDWARE

|$10

6732-21-1960

PLUG, THREADED (M10-1.00x9.5)

9

NSS

PLUG, THREADED (M10-1.00x9.5)

10

6215-81-9710

SEAL, O-RING

11

6216-94-3450

DRAINCOCK

12

6742-01-3890

NOZZLE, PISTON COOLING

13

6732-21-6120

DOWEL, PIN

14

6742-01-1470

DOWEL, PIN

15

6742-01-1480

PLUG, EXPANSION

16

6742-01-4080

SEAL, O-RING

17

6742-01-1460

PLUG, PIPE

|$20

6742-01-5159

KIT, LINER

18

NSS

LINER, CYLINDER

19

6742-01-1520

SEAL, RECTANGULAR RING

|$23

6735-21-1910

PLUG, THREADED

20

6735-21-1930

SEAL, O-RING

21

NSS

PLUG, THREADED

22

6732-11-1910

PLUG, PIPE

|$27

6732-11-1920

PLUG, PIPE

|$28

6735-21-1910

PLUG, THREADED

|$29

6735-21-1930

SEAL, O-RING

|$30

NSS

PLUG, THREADED

|$31

6732-21-1960

PLUG, THREADED (M10-1.00x9.5)

|$32

NSS

PLUG, THREADED (M10-1.00x9.5)

|$33

6215-81-9710

SEAL, O-RING (M10-1.00)

|$34

6735-21-1910

PLUG, THREADED (M14-1.50)

|$35

NSS

PLUG, THREADED (M14-1.50)

|$36

6735-21-1930

SEAL, O-RING

|$37

6732-11-1920

PLUG, PIPE

|$38

6742-01-1380

PLUG, EXPANSION
