Запчасти Komatsu PC300HD-7L H-9A ОСНОВН. КЛАПАН W/ АКТУАТОР - PRESSURE COMPENSATION КЛАПАНS ГИДРАВЛИКА

|$1

NSS

BODY SUB ASSEMBLY

1

709-74-91510

PLUG

2

07000-13024

O-RING

3

07000-11009

O-RING

4

07001-01009

RING, BACK-UP

|$6

723-40-91200

VALVE ASSEMBLY, PRESSURE COMPENSATION

5

NSS

SLEEVE

6

NSS

SLEEVE

7

NSS

POPPET

8

NSS

PISTON

9

NSS

PLUG

10

NSS

POPPET

11

NSS

SPACER

12

NSS

SPRING

13

NSS

SPRING

14

NSS

SPRING

15

NSS

SEAL

16

NSS

SEAL

17

709-25-11390

O-RING

18

NSS

O-RING

19

NSS

O-RING

20

NSS

NUT

21

NSS

NUT

|$24

723-40-66300

VALVE ASSEMBLY, LS SHUTTLE

22

NSS

CASE

23

NSS

SEAT

24

NSS

SEAT

25

NSS

BALL

26

NSS

PLUG

27

01252-60845

BOLT

28

01643-50823

WASHER
