Запчасти Komatsu PC300HD-7L H-A ОСНОВН. КЛАПАН НАСОС MERGE DIVIDER КЛАПАН ГИДРАВЛИКА

|$1

723-40-71201

VALVE ASSEMBLY

1

NSS

BODY

2

NSS

SPOOL

3

NSS

PLUG

4

723-40-71330

RETAINER

5

723-40-71340

SPRING

6

01252-60816

BOLT

7

723-46-15111

CASE

8

723-40-71350

RETAINER

9

07430-71380

O-RING

10

01252-60820

BOLT

11

NSS

SPOOL

12

723-40-71440

SPRING

13

NSS

PLUG

14

709-74-91860

PLUG

15

07002-12434

O-RING

16

NSS

SPOOL

17

723-40-71390

SPRING

18

723-40-61150

PLUG

19

07002-12434

O-RING

|$21

NSS

VALVE ASSEMBLY, RELIEF

20

NSS

SLEEVE

21

702-21-55750

COLLAR

22

702-21-55760

FILTER

23

NSS

POPPET

24

NSS

SPRING

25

NSS

SCREW

26

NSS

NUT

27

723-11-19660

O-RING

28

702-16-53920

O-RING

29

NSS

O-RING

30

07002-11623

O-RING
