Запчасти Komatsu PC300HD-7E0 ГУСЕНИЦЫ ХОДОВАЯ

|$0

208-32-03410

TRACK SHOE ASS'Y,700MM WIDE

1

208-32-61123

LINK

2

208-32-61133

LINK

3

154-32-11283

SEAL

4

208-32-61171

BUSHING

5

208-32-61141

BUSHING

6

208-32-61151

PIN

7

208-32-61310

SHOE

8

208-32-51210

BOLT, SHOE

9

208-32-71220

NUT, SHOE

10

208-32-61260

SEAL

11

208-32-51190

PIN

|$13

208-32-03420

TRACK SHOE ASS'Y,800MM WIDE

1

208-32-61123

LINK

2

208-32-61133

LINK

3

154-32-11283

SEAL

4

208-32-61171

BUSHING

5

208-32-61141

BUSHING

6

208-32-61151

PIN

7

208-32-61320

SHOE

8

208-32-51210

BOLT, SHOE

9

208-32-71220

NUT, SHOE

10

208-32-61260

SEAL

11

208-32-51190

PIN

|$26

208-32-03430

TRACK SHOE ASS'Y,900MM WIDE

1

208-32-61123

LINK

2

208-32-61133

LINK

3

154-32-11283

SEAL

4

208-32-61171

BUSHING

5

208-32-61141

BUSHING

6

208-32-61151

PIN

7

208-32-61340

SHOE

8

208-32-51210

BOLT, SHOE

9

208-32-71220

NUT, SHOE

10

208-32-61260

SEAL

11

208-32-51190

PIN

|$39

208-32-05080

SHOE BOLT AND NUT K.

8

208-32-51210

BOLT, SHOE

9

208-32-71220

NUT, SHOE
