Запчасти Komatsu PC300-8M0 СТАРТЕР (7.KW)(8789-UP) A

|$1

600-863-5712

STARTING MOTOR ASS'Y, 7.5KW

1

KD0-23100-0251

ARMATURE ASS'Y

2

KD1-045-462047

BEARING, BALL

3

KD1-045-462007

BEARING, BALL

4

KD0-23200-0334

YOKE ASS'Y

5

KD0-23310-1734

BRACKET

6

KD7-23351-0085

METAL

7

KD1-024-006305

BOLT

8

KD7-23120-0310

SHAFT ASS'Y

9

KD1-045-460067

BEARING, BALL

10

KD1-23181-0020

STOPPER

11

KD1-23914-0020

RING

12

KD1-23500-0974

CLUTCH ASS'Y

13

KD0-23600-0460

BRACKET ASS'Y

14

KD0-23611-0692

BRACKET

15

KD1-0240-08405

BOLT

16

KD7-23320-0060

SHIFT LEVER ASS'Y

17

KD0-47100-0244

SWITCH ASS'Y, MAGNETIC

18

KD0-027-406202

BOLT

|$20

KD7-23700-0524

BRACKET ASS'Y

19

KD0-23700-0130

BRACKET ASS'Y

20

KD0-23750-0124

BRUSH ASS'Y

21

KD1-23913-0040

BRUSH

22

KD0-23740-0254

BRUSH

23

KD0-09001-4580

BOLT

24

KD0-23901-0170

BOLT

25

KD0-25000-8333

SWITCH

26

KD0-027-006402

BOLT

27

KD1-47927-1250

HOLDER

28

KD1-23921-0130

WASHER

29

KD1-23921-0140

WASHER

30

KD1-23941-0040

WASHER, INSULATE

31

KD0-23921-0230

WASHER

32

KD7-09210-2830

SEAL ASS'Y

33

KD7-47761-0010

COVER ASS'Y

34

KD7-47761-0030

COVER ASS'Y
