Запчасти Komatsu PC300-8M0 КОВШ .M (ME КОВШ)(STD) T

1

776-920-62C1

BUCKET

2

776-920-62D2

LIP WELD (WELDED)

3

776-920-62F1

RANSEL (WELDED)

4

776-920-62R1

SIDE WALL R.H (WELDED)

5

776-V65-G141

LOGO KOMATSU (WELDED)

6

776-920-62S1

SIDE WALL L.H (WELDED)

7

776-V65-G141

LOGO KOMATSU (WELDED)

8

776-920-6341

PLATE (WELDED)

9

776-920-6351

PLATE (WELDED)

10

776-920-6361

PLATE (WELDED)

11

776-920-6372

PLATE (WELDED)

12

776-920-6382

PLATE (WELDED)

13

776-920-62N2

PLATE (WELDED)

14

776-920-62P2

PLATE (WELDED)

15

776-920-6462

PLATE (WELDED)

16

208-934-6C70

PLATE (WELDED)

17

208-934-6C80

PLATE (WELDED)

18

776-920-63B0

PLATE (WELDED)

19

776-920-6420

VERTICAL SHROUD

20

776-920-6430

PIN SHROUD

21

776-920-6220

TOOTH

22

776-920-6410

PIN TOOTH

23

207-70-72470

BUSHING

24

207-70-34230

BUSHING

25

207-70-34260

SHIM

26

207-70-34250

SHIM

27

207-70-34240

COVER

28

01010-82065

BOLT

29

01643-32060

WASHER

30

776-V65-6250

NAME PLATE

31

776-V65-5120

RIVET
