Запчасти Komatsu PC300-8M0 РУКОЯТЬ (ЦИЛИНДР КОВША)(.M)(100 ЧАСОВ)(STD) T

|$1

707-E1-02470

CYLINDER ASS'Y

1

707-13-15570

CYLINDER

2

707-58-11850

ROD, PISTON

3

707-76-90130

BUSHING

4

07145-00090

SEAL, DUST (K23)

5

07020-00000

FITTING, GREASE

6

207-63-76170

BUSHING

7

207-70-72120

SEAL, DUST (K23)

8

07020-00000

FITTING, GREASE

9

707-27-15620

HEAD, CYLINDER

10

707-56-11740

SEAL, DUST (K23)

11

07179-13126

RING, SNAP

12

707-51-11860

PACKING, ROD (K23)

13

707-51-11650

RING, BUFFER (K23)

14

707-35-31410

RING, BACK-UP (K23)

15

07000-B5140

O-RING (K23)

16

707-52-90851

BUSHING

17

707-75-11040

RING, SNAP

18

01010-82085

BOLT

19

707-88-75310

WASHER

20

707-36-15260

PISTON

21

707-44-15150

RING, PISTON (K23)

22

707-39-15110

RING, WEAR (K23)

23

707-44-15911

RING

24

707-35-31000

RING, BACK-UP (K23)

25

07000-B5100

O-RING (K23)

26

01310-01216

SCREW

27

707-86-00920

TUBE

28

207-63-73181

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-B3035

O-RING (K23)

32

707-88-22692

BRACKET

33

707-88-21420

BAND

34

07372-21240

BOLT

35

01643-51232

WASHER

36

707-88-10150

CLAMP

37

01010-81245

BOLT

38

01643-31232

WASHER

39

07371-31049

FLANGE, SPLIT

40

707-88-33040

CAP

41

07372-21035

BOLT

42

01643-51032

WASHER
