Запчасти Komatsu PC300-8M0 РУКОЯТЬ (ЦИЛИНДР КОВША)(.M) T

|$1

707-E1-02470

CYLINDER ASS'Y

1

707-13-15570

Cylinder

2

707-58-11850

Rod, Piston

3

707-76-90130

Bushing

4

07145-00090

Seal, Dust, (K21)

5

07020-00000

FITTING, GREASE

6

207-63-76170

Bushing

7

207-70-72120

Seal, Dust, (K21)

8

07020-00000

FITTING, GREASE

9

707-27-15620

Head, Cylinder

10

707-56-11740

Seal, Dust, (K21)

11

07179-13126

Ring, Snap

12

707-51-11860

Packing, Rod, (K21)

13

707-51-11650

Ring, Buffer, (K21)

14

707-35-31410

Ring, Back-up, (K21)

15

07000-B5140

O-ring, (K21)

16

707-52-90851

Bushing

17

707-75-11040

Ring, Snap

18

01010-82085

BOLT

19

707-88-75310

Washer

20

707-36-15260

Piston

21

707-44-15150

Ring, Piston, (K21)

22

707-39-15110

Ring, Wear, (K21)

23

707-44-15911

Ring

24

707-35-31000

Ring, Back-up, (K21)

25

07000-B5100

O-ring, (K21)

26

01310-01216

Screw

27

707-86-00920

Tube

28

207-63-73181

Tube

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-ring, (K21)

32

707-88-22692

Bracket

33

707-88-21420

Band

34

07372-21240

BOLT

35

01643-51232

WASHER

36

707-88-10150

Clamp

37

01010-81245

BOLT

38

01643-31232

WASHER

39

07371-31049

FLANGE

40

707-88-33040

Cap

41

07372-21035

BOLT

42

01643-51032

WASHER
