Запчасти Komatsu PC300-8M0 РУКОЯТЬ (ЦИЛИНДР КОВША)(.M) T

|$1

707-F1-X2190

CYLINDER G.

|$2

707-E1-02190

CYLINDER A

1

721-13-14060

TUBE

2

721-58-10410

ROD,PISTON

3

707-76-90130

BUSHING

4

07145-00090

SEAL (K22)

5

07020-00000

FITTING

6

207-63-76170

BUSHING

7

207-70-72120

SEAL.DUST (K22)

8

07020-00000

FITTING

9

707-27-14690

HEAD,CYLINDER

10

707-56-10740

SEAL DUST (K22)

11

07179-13114

RING,SNAP

12

707-51-10860

PACKING,ROD (K22)

13

707-51-10650

RING,BUFFER (K22)

14

707-52-90781

BUSHING

15

07000-B5130

O-RING (K22)

16

707-35-31310

RING,BACK-UP (K22)

17

01010-81875

BOLT

18

707-41-11840

WASHER

19

707-75-10160

RING,SNAP

20

707-36-14650

PISTON

21

707-44-14150

RING,PISTON (K22)

22

707-39-14110

RING,WEAR (K22)

23

707-44-14910

RING (K22)

24

07000-B5090

O-RING (K22)

25

707-35-30900

RING,BACK-UP

26

SCREW

27

707-86-16330

TUBE

28

207-63-73181

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-RING (K22)

32

707-88-51380

BRACKET

33

707-88-21410

BAND

34

07375-21240

BOLT

35

01643-51232

WASHER

36

707-88-10150

CLAMP

37

01010-81245

BOLT

38

01643-31232

WASHER

39

07371-31049

FLANGE

40

707-88-33040

CAP

41

07372-21035

BOLT

42

01643-51032

WASHER
