Запчасти Komatsu PC300-8M0 ЦИЛИНДР СТРЕЛЫ, L.H T

|$1

707-E1-02480

CYLINDER ASSEMBLY

1

721-13-14050

CYLINDER

2

721-58-10400

ROD,PISTON

3

707-76-90390

BUSHING

4

07145-00090

SEAL, (K11)

5

07020-00000

FITTING

6

07043-00108

PLUG

7

707-76-10130

BUSHING

8

07145-00100

SEAL, DUST, (K11)

9

707-71-35220

COLLAR

10

707-35-31310

RING,BACK-UP, (K11)

11

07000-B5130

O-RING, (K11)

12

707-71-71060

PLUNGER

13

707-27-14690

HEAD,CYLINDER

14

707-56-10740

SEAL DUST, (K11)

15

07179-13114

RING,SNAP

16

707-52-90781

BUSHING

17

707-51-10860

PACKING,ROD, (K11)

18

707-51-10650

RING,BUFFER, (K11)

19

707-35-31310

RING,BACK-UP, (K11)

20

07000-B5130

O-RING, (K11)

21

01010-81875

BOLT

22

707-41-11840

WASHER

23

707-75-10160

RING,SNAP

24

707-36-14650

PISTON

25

707-44-14150

RING,PISTON, (K11)

26

707-39-14110

RING,WEAR, (K11)

27

707-35-30900

RING,BACK-UP, (K11)

28

07000-B5090

O-RING, (K11)

29

707-44-14910

RING

30

01310-01216

SCREW

31

707-86-00810

TUBE,L.H.

32

707-86-00860

TUBE,L.H.

33

707-87-14700

PLUG

34

07002-63034

O-RING, (K11)

35

BRACKET

36

07372-21060

BOLT

37

01643-51032

WASHER

38

07000-13035

O-RING, (K11)

39

707-88-21370

BAND

40

07372-21240

BOLT

41

01643-51232

WASHER

42

07283-33442

CLIP

43

01597-01009

NUT

44

01643-31032

WASHER

45

01010-81025

BOLT
