Запчасти Komatsu PC300-8M0 НЕСУЩИЙ ЭЛЕМЕНТ, R.H 6776 303

|$1

207-27-00590

FINAL DRIVE ASSY

|$2

207-27-00510

FLOATING SEAL A

1

SEAL

2

O-RING

3

207-27-72290

HUB

4

207-27-72220

BEARING

5

207-27-52350

O-RING

6

207-27-72260

LOCK

7

207-27-72250

NUT,LOCK

8

01010-81020

BOLT

9

207-27-72170

CARRIER

10

207-27-72140

GEAR

11

207-27-72210

BEARING

12

21M-27-11260

THRUST WASHER

13

208-27-71250

PIN

14

20Y-27-21290

PIN

15

20Y-27-13310

THRUST WASHER

16

207-27-72130

GEAR

17

207-27-72150

GEAR

18

207-27-72240

WASHER,THRUST

19

207-27-72160

CARRIER

20

207-27-72120

GEAR

21

22U-26-21320

BEARING

22

206-26-71520

THRUST WASHER

23

207-27-72230

PIN

24

20Y-27-21280

PIN

25

207-27-72110

SHAFT

26

20Y-27-11250

SPACER

27

04260-01905

BALL(CR3/4)

28

207-27-72180

COVER

29

01011-61890

BOLT

30

01643-31845

WASHER

31

07049-01215

PLUG

32

07044-12412

PLUG

33

07002-02434

O-RING

34

207-27-72270

SPROCKET

35

207-27-51311

BOLT
