Запчасти Komatsu PC300-8M0 МОТОР ХОДА, L.H (/) 6776 303

|$1

207-27-00580

FINAL DRIVE ASS'Y

|$2

708-8H-00440

MOTOR ASSY

1

708-8H-32180

SHAFT

2

708-8H-32150

BEARING

3

708-8H-32170

BEARING

4

708-8H-05050

SPACER KIT

|$7

SPACER,T=1.6MM

|$8

SPACER, T=1.7MM

|$9

SPACER, T=1.8MM

|$10

SPACER, T=1.9MM

|$11

SPACER, T=2.0MM

|$12

SPACER,T=2.1MM

|$13

SPACER,T=2.2MM

5

708-1F-12281

OIL SEAL

6

708-8H-32160

SPACER

7

04065-07825

RING,SNAP

|$17

708-8H-04860

CYLINDER B.A.

8

CYLINDER BLOCK

9

VALVE PLATE

10

708-18-13230

PIN

11

708-8H-33360

PIN

12

708-8H-33141

SPACER

13

708-8H-33750

SPRING

14

04065-06020

RING

15

708-8H-33512

RETAINER

16

708-8H-33340

RETAINER,SHOE

17

708-8H-33650

PISTON SUB A.

18

708-8H-33940

CAM,ROCKER

19

04260-02857

BALL

20

708-8H-34320

PISTON

21

708-8H-34330

SPRING

22

708-8H-35130

PLATE

23

708-8H-35180

DISC

24

708-8H-35141

PISTON,BRAKE

25

07000-15175

O-RING

26

07001-05175

RING BACK UP

27

07000-15195

O-RING

28

07001-05195

RING BACK UP

29

708-8H-35150

SPRING
