Запчасти Komatsu PC300-8M0 УПРАВЛЯЮЩ. КЛАПАН (7-СЕКЦИОНН.)(/) H

|$1

723-47-25603

CONTROL VALVE

|$2

723-47-25602

CONTROL VALVE

|$3

723-47-25601

CONTROL VALVE

|$4

723-47-25600

CONTROL VALVE

|$5

723-40-71201

VALVE ASS'Y

1

723-40-71513

BODY, VALVE

2

723-40-71520

SPOOL

3

708-21-12541

PLUG

4

723-40-71330

RETAINER

5

723-40-71340

SPRING

6

01252-60816

BOLT

7

723-46-15111

CASE

8

723-40-71350

RETAINER

9

07430-71380

O-RING

10

01252-60820

BOLT

11

723-40-71362

SPOOL

12

723-40-71440

SPRING

13

708-21-12541

PLUG

14

709-74-91860

PLUG

15

07002-12434

O-RING

16

723-40-71380

SPOOL

17

723-40-71390

SPRING

18

723-40-61150

PLUG

19

07002-12434

O-RING

|$25

723-40-71800

VALVE ASS'Y

20

723-40-91600

RELIEF VALVE

21

702-16-53920

O-RING

22

07002-11623

O-RING

23

723-40-71411

BLOCK

24

702-21-55511

SPOOL

25

702-21-55640

SPRING

26

702-21-55620

PLUG

27

708-8H-11530

PLUG

28

07002-11423

O-RING

29

702-21-55710

SEAT

30

702-21-55720

SPRING

31

04260-00793

BALL

32

07000-11009

O-RING

33

708-21-12541

PLUG
