Запчасти Komatsu PC300-8M0 УПРАВЛЯЮЩ. КЛАПАН (7-СЕКЦИОНН.) (9/) H [ГИДРАВЛИКА]

-

723-47-25602

VALVE ASSEMBLY, CONTROL

-

723-47-25601

VALVE ASSEMBLY, CONTROL

-

723-40-82401

VALVE ASSEMBLY

1

BODY

-

BODY

2

VALVE

3

SEAL

4

723-40-82210

PLUG

5

723-40-82220

FILTER

6

723-40-82140

SPRING

7

723-40-82150

PLUG

8

07002-13334

O-RING

9

723-40-84420

VALVE, CHECK

10

723-40-84430

SPRING

11

PLUG

-

PLUG

12

07000-13024

O-RING

13

PLUG

14

07002-11823

O-RING

15

07000-12011

O-RING

16

07001-02011

RING, BACK-UP

17

07000-11010

O-RING

18

07001-01010

RING, BACK-UP

19

723-11-18190

PLUG

20

07002-11023

O-RING

21

PISTON

22

723-40-82290

SPRING

23

PLUG

24

01252-61075

BOLT, HEXAGON SOCKET HEAD
